The E-T-A 1115-F111-P1T1-6A is a single-pole thermal reset circuit breaker offering a space-saving, slim design with ease of installation through a snap-in frame. It incorporates a reliable, trip-free mechanism and is approved to UL1077 and EN60934 standards.
Key electrical specifications include a rated voltage of AC 250V and DC 32V, with a current rating range from 1A to 16A. This specific model is rated for 6A. The breaker type is thermal, with characteristic curves T1 (3-16A) and T2 (1-2.5A) available. It supports panel mounting and features blade terminals.
Typical applications for this circuit breaker include power supply units, UPS equipment, battery chargers, oxygen treatment devices, and office machines. The operating ambient temperature range is -20°C to +60°C. The device has a rupture capacity of 1000A at AC 250V and 200A at DC 32V.
The current rating is 6A.
The rated voltage is AC 250V and DC 32V.
It is designed for panel mounting.
Typical applications include power supply units, UPS equipment, battery chargers, oxygen treatment devices, and office machines.
The ambient temperature range is -20°C to +60°C.
