111382-4 TE Connectivity 111382-4 is a 20-position IDC DIP header for ribbon cable, with 2 rows, 2.54mm row spacing, through-hole press-fit mounting, and tin-lead contact finish.
Mfr Part #:

111382-4

Available from 1 distributors
Mfr Name: TE Connectivity
TE Connectivity
TE Connectivity 111382-4 is a 20-position IDC DIP header for ribbon cable, with 2 rows, 2.54mm row spacing, through-hole press-fit mounting, and tin-lead contact finish.
✓ Total Stock: 1,000 pcs
$ Price Range: $2.22

111382-4 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
1,000 pcs
On Request
1000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

111382-4 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Board
Cable Pitch
Cable Termination
Color
Connector Type
Contact Finish
Contact Finish Thickness
Features
Lead Spacing
Lead Style
Mounting Type
Number of Positions
Number of Rows
Row Spacing
Tape & Reel
Wire Gauge
View Similar Products (0)

111382-4 Description

Short technical summary and product information.

The TE Connectivity 111382-4 is a 20-position IDC DIP header designed for direct wiring to board applications. It features 2 rows with a 2.54mm row spacing, and a cable pitch of 1.27mm. The connector uses IDC termination for 28 AWG stranded or 26-30 AWG solid wire. Mounting is through-hole press-fit. The contact finish is tin-lead with a thickness of 100.0µin (2.54µm). The housing is black and includes a feed-through feature. This header is suitable for use in applications requiring a reliable connection between ribbon cable and PCB.

111382-4 Quick Information

Product Type: IDC DIP Header
Canonical Name: TE Connectivity 111382-4 20 Position IDC DIP Header
Subcategory: Ribbon Cable Connectors

111382-4 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): Level 1 Unlimited
REACH Status: Non-Compliant

111382-4 Estimated Pricing

Qty Low High
1,400+ $2.22 $2.22

Estimated market price range - modelled values for guidance only, not live distributor offers.

111382-4 Features

  • 20-position DIP header for IDC ribbon cable.
  • 2 rows with 2.54mm (0.100") row spacing.
  • 1.27mm (0.050") cable pitch.
  • Through-hole press-fit mounting.
  • Tin-lead contact finish with 100µin thickness.

111382-4 Applications

  • Ideal for connecting ribbon cables to PCBs.
  • Used in board-in direct wire to board applications.
  • Suitable for prototyping and production wiring.

111382-4 FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the 111382-4 have?

20 positions.

What is the row spacing?

2.54mm (0.100").

What is the cable pitch?

1.27mm (0.050").

What is the mounting type?

Through hole, press-fit.

What is the contact finish?

Tin-lead, 100.0µin (2.54µm) thickness.

What wire gauge is compatible?

28 AWG stranded, 26-30 AWG solid.

What is the termination method?

IDC (Insulation Displacement Connection).
