| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Insulation Resistance | |
| Isolation | |
| Length | |
| Mounting Type | |
| No Load Power Consumption | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Voltage | |
| Package / Case | |
| Power | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The GAPTEC Electronic 10ACEW_05S4A is a 10 Watt AC-DC converter designed for industrial and commercial applications. It offers an ultra-wide input voltage range of 85-305VAC and 100-430VDC, making it versatile for various power environments.
Key electrical specifications include a 3.3V single output, 2A current capability, and up to 85% efficiency. The converter operates within an ambient temperature range of -40°C to +85°C and features short circuit protection with self-recovery.
This AC-DC converter is housed in a 5-DIP Module package and is designed for through-hole mounting. It meets EMI performance standards such as CISPR32/EN55032 Class B and is safety approved to IEC/EN/UL62368, EN60335, and EN61558 standards.
Applications include household appliances, ITE (Commercial), industrial, power, medical treatment, instrumentation, communication, and civil applications. The converter provides reinforced isolation and good EMC performance.
The input voltage range is 85-305 VAC or 100-430 VDC.
The package is a 5-DIP Module with 4 leads, through hole mounting.
The operating temperature range is -40°C to 85°C with derating.
The output is 3.3V at 2A, providing 10W.
Typical efficiency is 85%.
Yes, it has hiccup mode short circuit protection with continuous self-recovery.
