| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5 pcs
|
5 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request | |
|
3 pcs
|
3 pcs | On Request | 1 | On Request | On Request | NO DC | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Base Material | |
| Battery Cell Size | |
| Battery Series | |
| Battery Type, Function | |
| Contact Material | |
| Contact Thickness | |
| Height Above Board | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Cells | |
| Operating Temperature | |
| Storage Temperature | |
| Style | |
| Termination Style |
The Keystone Electronics 1067 is a through-hole PCB mount coin cell battery holder designed for single 20mm coin cells. It features a PC pin termination style for secure soldering to the PCB. The holder accepts battery series 2012, 2016, 2020, 2025, and 2032.
The holder is constructed with a PBT base rated UL 94V-0 and spring steel contacts with a tin-nickel plate. The contact thickness is 0.30mm. The height above board is 19.94mm (0.785 inches).
This open-style holder is suitable for applications requiring a reliable and replaceable coin cell power source. The operating temperature range is -50°C to 145°C.
The holder accepts 20mm coin cell battery series 2012, 2016, 2020, 2025, and 2032.
The operating temperature range is -50°C to 145°C.
The mounting type is PCB, Through Hole with PC Pin termination.
The part is listed as RoHS3 Compliant, though this is unverified.
