| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,921 pcs
|
1921 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Resistance | |
| Contact Shape | |
| Contact Type | |
| Current - Max | |
| Cycles | |
| Dielectric Withstanding Voltage | |
| Fastening Type | |
| Features | |
| Halogen Free | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Insulation Resistance | |
| Mating Force | |
| Medical Grade | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| SVHC Present | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Unmating Force | |
| Voltage Rating |
The Molex 1053112204 is a 4-position, single-row header from the Nano-Fit Power Connector series. It features a 2.50mm pitch and is designed for board-to-cable/wire applications. The header is shrouded with a 4-wall design and has a latch holder for secure mating. It is rated for 8.0A per contact and 250V, with an operating temperature range of -40°C to 105°C. The contacts are made of brass with tin plating (15µin), and the insulation is Liquid Crystal Polymer (LCP) in natural color. Additional features include board guide and board lock for alignment and retention. The header is through-hole mounted with solder termination. Electrical specifications: contact resistance 10 milliohms, dielectric withstanding voltage 1500V, insulation resistance 1000 Megohms. Mating and unmating forces are 3N each, with a durability of 20 cycles for tin plating. The part is RoHS compliant and halogen-free. Typical applications include consumer appliances, telecommunications networking equipment, and automotive interior lighting.
4 positions in a single row.
2.5mm.
8.0A per contact.
250V.
Through Hole with solder termination.
-40°C to 105°C.
Tin with 15µin thickness.
