This E-T-A 105-P10-3A is a miniaturized, single-pole thermal circuit breaker designed for reliable switching behavior. It meets the requirements of the circuit breaker standard EN 60934 (IEC 60934).
Key electrical specifications include a rated voltage of 240V AC and 48V DC, with a current rating of 3A. The breaking capacity is 25A. It offers a thermal tripping mechanism and a push-to-reset actuator.
Designed for panel mounting, this circuit breaker is suitable for a wide range of applications including hand tools, domestic appliances, overcurrent protection of PCB conductor paths, marine vehicles, and mobile homes. Environmental specifications include an operating temperature range of -20 to 60 °C and an ingress protection rating of IP40 for the operating area.
Compliance includes RoHS3, REACH Unaffected, and MSL 1 Unlimited. The device is built to withstand vibration, shock, and corrosion as per IEC standards.
It is rated for 250VAC and 48VDC.
-20°C to 60°C.
25A.
Push-to-reset.
1 pole.
Panel mount with screw terminals.
2000A at 250VAC and 200A at 48VDC.
