| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
56 pcs
|
56 pcs | On Request | 1 | On Request | On Request | 96 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination |
The TE Connectivity 104656-1 is a surface mount header designed for board-to-board interconnections. This connector offers 10 positions arranged in 2 rows with a 1.27mm pitch and 1.27mm row spacing, enabling compact PCB layouts. The header features a fully shrouded 4-wall design with a push-pull fastening system and an integrated board lock for secure mechanical retention during soldering.
Constructed with a black liquid crystal polymer (LCP) insulator rated UL94 V-0, the header provides reliable insulation and flame resistance. The male pin contacts are made of phosphor bronze with a tin-lead finish (30µin thickness), suitable for solder termination. The component is rated for a current of 0.5A per contact and operates over a temperature range of -65°C to 105°C.
This connector is intended for surface mount assembly and is compatible with standard soldering processes. The enclosure includes a board lock feature that helps hold the component in place during reflow. While RoHS, MSL, and REACH compliance are indicated, these statuses are unverified and should be confirmed with the manufacturer for critical applications.
10 positions, all loaded.
1.27mm (0.050")
0.5A per contact.
Surface mount.
-65°C to 105°C.
Phosphor bronze.
Tin-lead, 30µin thickness.
