| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
500 pcs
|
500 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
12 pcs
|
12 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The TE Connectivity 104069-7 is a 60-position shrouded header designed for board-to-board or cable interconnection. It features two rows of male pins on a compact 1.27mm pitch, with a right-angle through-hole mounting style for space-constrained designs.
This connector is housed in a black thermoplastic insulator rated UL94 V-0 and includes a board guide feature. The contacts are made of copper alloy with a 30µin tin-lead finish, providing reliable electrical performance. A latch holder fastening type ensures secure mating.
Rated for 30VAC and an operating temperature range of -65°C to 105°C, this header is suitable for a variety of moderate-signal-density applications. The insulation height is 7.37mm and row spacing is 2.54mm.
The pitch is 1.27mm (0.050").
It has 60 positions, all loaded, arranged in 2 rows.
It is through hole, right angle mounting.
The voltage rating is 30VAC.
RoHS status is unverified; there is a conflict between distributor data indicating non-compliant and precomputed data indicating RoHS3 compliant. Verify with manufacturer official documentation.
The operating temperature range is -65°C to 105°C.
The contact finish is tin-lead with a thickness of 30µin (0.76µm).
