| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
64 pcs
|
64 pcs | On Request | 1 | On Request | On Request | 0603 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Cable Termination | |
| Color | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Type | |
| Fastening Type | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Pitch | |
| Tape & Reel | |
| Termination Style | |
| Wire Gauge | |
| Wire Type |
The TE Connectivity 103956-2 is a 3-position, 1-row IDC receptacle connector designed for discrete wire termination. It accepts 22-26 AWG wires and uses insulation displacement contacts (IDC) for quick, reliable termination without stripping. The connector is free-hanging (in-line) with a latch lock mechanism that ensures secure mating with corresponding headers. The female socket contacts have a tin-lead finish with a thickness of 100µin (2.54µm). The housing is black and features a 2.54mm (0.100") pitch. This part is listed as RoHS3 compliant and REACH unaffected. It is cross-referenced as distributor part number A28396-ND. The connector is suitable for internal wire-to-board connections in a variety of electronic assemblies.
3 positions.
2.54mm (0.100").
Free hanging (in-line).
22-26 AWG.
IDC (Insulation Displacement Connection).
Tin-lead with 100µin (2.54µm) thickness.
Latch lock.
