| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
145 pcs
|
145 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current Rating | |
| DC Resistance | |
| Inductance | |
| Inductance @ Frequency | |
| Mounting Type | |
| Operating Temperature | |
| Self Resonant Frequency | |
| Tolerance |
The Bourns Inc. 9230-84 is a fixed inductor designed for various electronic applications. It offers an inductance value of 470 µH with a tolerance of ±10%, ensuring reliable performance in circuits requiring specific inductance characteristics.
This inductor has a current rating of 50 mA and a maximum DC resistance of 42 Ohms. It operates within a temperature range of -55°C to 125°C. The component features a Q factor of 30 at 790 kHz and a self-resonant frequency of 6 MHz, making it suitable for signal processing and filtering tasks.
Designed with a molded construction, the 9230-84 utilizes an unshielded ferrite core. It is mounted via a through-hole configuration and comes in an axial package. The dimensions of the inductor are 2.41mm in diameter and 6.35mm in length. This part is supplied in a standard package of 1000 pieces.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance of the 9230-84 is 470 µH.
The current rating for the 9230-84 is 50 mA.
The maximum DC resistance (DCR) for the 9230-84 is 42 Ohms.
The operating temperature range for the 9230-84 is -55°C to 125°C.
The 9230-84 is mounted using a through-hole configuration.
