| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
50 pcs
|
50 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination |
The 102203-5 is a rectangular connector header from TE Connectivity designed for board-to-board or cable-to-board applications. It features 8 positions in a single row with a 2.54mm pitch. Mounting is through hole right angle with solder termination, and the connector is fully shrouded with four walls for robust mating. The contact material is phosphor bronze with a tin-lead finish of 15µin, and the insulator is black thermoplastic rated UL94 V-0. Electrical rating is 3A, and the operating temperature range spans -65°C to 105°C. This header uses a push-pull fastening mechanism and square contact shape. It is suitable for general purpose signal interconnections in various electronic assemblies.
8 positions.
2.54mm (0.100 inches).
3A.
Through hole, right angle.
Yes, shrouded with 4 walls.
-65°C to 105°C.
Tin-lead, 15µin (0.38µm) thickness.
