| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
36,869 pcs
|
36869 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Accessory Type | |
| Automotive Grade | |
| Color | |
| For Use With | |
| Halogen Free | |
| Number of Positions | |
| Operating Temperature Range | |
| SVHC Present | |
| UL Flammability Rating |
The TE Connectivity 1011-241-0605 is a backshell accessory for the DEUTSCH DT series of rectangular connectors. It supports 6 positions and is constructed from polyamide glass fiber (PA GF) in black. This backshell features a 180° cable exit angle and accepts cable diameters from 8.5 to 13 mm.
It is rated IP6K9K for dust and high-pressure water ingress protection and carries a UL 94HB flammability rating. The part is serviceable and operates over a temperature range of -55 to 125 °C. It is not sealable.
Packaged in a box of 350 units, this backshell is RoHS, ELV, China RoHS, and REACH compliant with low halogen content. Solder process capability has not been reviewed.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.66 | $2.66 |
| 10+ | $2.32 | $2.32 |
| 25+ | $2.08 | $2.08 |
| 100+ | $1.98 | $1.98 |
| 250+ | $1.82 | $1.82 |
| 350+ | $1.75 | $1.75 |
| 1,050+ | $1.57 | $1.57 |
| 2,800+ | $1.54 | $1.54 |
| 5,250+ | $1.51 | $1.51 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
This backshell supports 6 positions.
It has an IP6K9K rating.
It is made of polyamide glass fiber (PA GF).
The cable exit angle is 180°.
The operating temperature range is -55 to 125 °C.
It accepts cable diameters from 8.5 to 13 mm.
Yes, it is EU RoHS Directive 2011/65/EU compliant.
