Mfr Part #:

100DP8T6B11M2QEH

Name: 100DP8T6B11M2QEH
Brand: E-Switch
SKU: 100DP8T6B11M2QEH

Mfr Name: E-Switch

Description:

SWITCH TOGGLE SP3T 5A 120V

Stock on Request

100DP8T6B11M2QEH Description

Short technical summary and product information.

SWITCH TOGGLE SP3T 5A 120V

Mfr Standard Lead Time: 12 weeks (varies by distributor)

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Category	Toggle Switches
Manufacturer Name	E-Switch
Actuator Length	12.30mm
Actuator Type	Flat Anti-Rotation
Bushing Thread	1/4-40
Circuit	SP3T
Current Rating (Amps)	5A (AC/DC)
Features	Jumper needed to achieve triple throw
Illumination	Non-Illuminated
Mounting Type	Panel Mount
Operating Temperature	-30°C ~ 85°C
Panel Cutout Dimensions	Circular - 6.35mm Dia
Switch Function	Mom-On-Mom
Termination Style	PC Pin
Voltage Rating	28 V
