| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
950 pcs
|
950 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
350 pcs
|
350 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Backset Spacing | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Features | |
| Flange Feature | |
| Halogen Free | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| SVHC Present | |
| Shell Material, Finish | |
| Shell Size | |
| Shell Size, Connector Layout | |
| Storage Temperature | |
| Termination | |
| Termination Style |
The Amphenol ICC 10090926-P444XLF is a 44-position D-Sub High Density plug connector with male pins. It uses a right angle through-hole solder termination for board edge mounting, making it suitable for dense PCB layouts where space is constrained.
Electrical specs include a current rating of 2.5A per contact with signal type contacts. The shell is steel with nickel plating, shell size 3 (DB, B) high density, and includes a board side 4-40 flange. The contact finish is gold with flash thickness.
Mechanical features include board lock, grounding indents, and mounting brackets. The insulator material has a UL94 V-0 flammability rating. The backset spacing is 0.350" (8.89mm).
2.5A per contact.
Solder termination, right angle through-hole.
44 positions in a high density D-Sub layout, 3 rows.
