| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,800 pcs
|
1800 pcs | On Request | 1 | On Request | On Request | 15+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Connector Style | |
| Connector Type | |
| Connector Usage | |
| Contact Finish | |
| Contact Layout, Typical | |
| Mounting Type | |
| Number of Columns | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Pitch | |
| Tape & Reel | |
| Termination |
The Amphenol ICC 10084160-101LF is a high density backplane header connector designed for dense signal interconnection in backplane systems. It features 288 positions arranged in an 18-row by 16-column grid with a 1.80mm pitch, enabling high pin count in a compact footprint.
The connector uses male pins with a through hole press-fit termination, providing a reliable solderless connection to the PCB. The contact finish is gold or Amphenol's GXT™, ensuring low contact resistance and corrosion resistance. The contact layout consists of 96 signal pairs and 96 ground contacts, suitable for differential signal applications.
Housed in a black thermoplastic, the connector is designed for backplane mounting and offers high mechanical stability. The press-fit termination reduces assembly time and eliminates soldering defects. This connector is commonly used in high-performance computing, networking, and telecommunications equipment where signal integrity and density are critical.
288 positions, all loaded.
1.80mm (0.071 inches).
Through hole mounting with press-fit termination.
18 rows by 16 columns.
Gold or Gold, GXT™.
96 signal pairs and 96 ground contacts (typical).
