| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
8 pcs
|
8 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Overall Contact Length | |
| Pitch | |
| Row Spacing | |
| SVHC Present | |
| Shrouding | |
| Style | |
| Termination | |
| Voltage Rating |
The Amphenol ICC 10075024-G01-05ULF is a 10-position, 2-row, 2mm pitch through-hole header designed for board-to-board or cable interconnects. It features unshrouded square male pins with tin plating (30µin) over copper alloy, ensuring reliable electrical contact. The thermoplastic insulator is rated UL94 V-0 for flammability resistance and is black in color.
With a current rating of 2A AC/DC and voltage rating of 200V AC/DC, this header is suitable for low-power signal and power applications. The through-hole solder termination provides robust mechanical attachment to PCBs. The overall contact length is 7.49mm, with an insulation height of 1.5mm.
This connector is part of Amphenol ICC's Minitek series (inferred from similar parts) and is commonly used in industrial, consumer, and telecommunications equipment where compact, reliable interconnections are required.
10 positions in 2 rows.
2.00mm (0.079").
2A AC/DC.
200V AC/DC.
Through hole.
Tin, 30µin (0.76µm).
Thermoplastic, UL94 V-0.
