10056845-108LF This is an 8-position, 2.54mm pitch, right-angle through-hole header with a shrouded 4-wall design and detent lock fastening.
Mfr Part #:

10056845-108LF

Available from 1 distributors
Mfr Name: Amphenol ICC
Amphenol ICC
This is an 8-position, 2.54mm pitch, right-angle through-hole header with a shrouded 4-wall design and detent lock fastening.
✓ Total Stock: 7 pcs
$ Price Range: $0.66 - $1.21

10056845-108LF Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Akira Global ✓
Non-Authorised Inventory information
7 pcs
On Request
7 pcs On Request 1 On Request On Request 2035 On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

10056845-108LF Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Fastening Type
Features
Insulation Color
Insulation Height
Insulation Material
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Pitch
Row Spacing
SVHC Present
Shrouding
Style
Tape & Reel
Termination
View Similar Products (0)

10056845-108LF Description

Short technical summary and product information.

The 10056845-108LF is an 8-position, 2-row header from Amphenol ICC designed for board-to-cable/wire connections. It features a 2.54mm (0.100") pitch and a right-angle through-hole mounting style with solder termination. The male pin contacts are made of copper alloy with a tin finish of 30.0µin (0.76µm) and have a square shape with a contact length of 6.00mm (0.236").



The header is fully shrouded with a 4-wall design and includes a detent lock fastening mechanism for secure mating. The insulation is black thermoplastic rated UL94 V-0, and the part includes a keying slot for polarization. The insulation height is 9.20mm (0.362").



This connector is suitable for applications requiring a reliable, polarized connection in a compact form factor. It is RoHS3 compliant, REACH unaffected, and has an MSL of 1 (unlimited).

10056845-108LF Quick Information

Product Type: Header, Male Pins
Canonical Name: 8 Position 2.54mm Pitch Right Angle Shrouded Header, Male Pins
Subcategory: Shrouded Header

10056845-108LF Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

10056845-108LF Estimated Pricing

Qty Low High
1+ $1.21 $1.21
25+ $0.94 $0.94
100+ $0.86 $0.86
500+ $0.78 $0.78
990+ $0.74 $0.74
5,940+ $0.66 $0.66

Estimated market price range - modelled values for guidance only, not live distributor offers.

10056845-108LF Features

  • 8-position dual-row right-angle header.
  • 2.54mm pitch for standard interconnects.
  • Shrouded 4-wall design with detent lock.
  • Tin-plated copper alloy contacts.
  • UL94 V-0 thermoplastic insulation.

10056845-108LF Applications

  • Board-to-cable/wire connections in industrial equipment.
  • Used in computing and peripheral devices.
  • Suitable for signal and power distribution.
  • Ideal for applications requiring keying slot.

10056845-108LF FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does this header have?

8 positions.

What is the pitch of this connector?

2.54mm (0.100").

What is the mounting type?

Through hole, right angle.

What is the contact finish?

Tin, 30.0µin (0.76µm).

Is this header shrouded?

Yes, it has a shrouded 4-wall design.

What is the insulation material and flammability rating?

Thermoplastic, UL94 V-0.

What fastening type does it use?

Detent lock.
