10034475-101LF High speed backplane receptacle with 150 positions, female sockets, board edge mount, and press-fit termination.
Mfr Part #:

10034475-101LF

Available from 1 distributors
Mfr Name: Amphenol ICC
Amphenol ICC
High speed backplane receptacle with 150 positions, female sockets, board edge mount, and press-fit termination.
✓ Total Stock: 4,600 pcs
$ Price Range: $22.47

10034475-101LF Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Optech Co.,Limited ✓
Non-Authorised Inventory information
4,600 pcs
On Request
4600 pcs On Request 1 On Request On Request 11+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

10034475-101LF Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Connector Style
Connector Type
Connector Usage
Contact Finish
Contact Finish Thickness
Contact Material
Current Rating
Durability
Halogen Free
Housing Material
Lead Spacing
Lead Style
Mounting Type
Number of Columns
Number of Positions
Number of Positions Loaded
Number of Rows
Pitch
Tape & Reel
Termination
Termination Style
View Similar Products (0)

10034475-101LF Description

Short technical summary and product information.

The Amphenol ICC 10034475-101LF is a high-speed backplane receptacle from the Airmax VS family. It features 150 positions arranged in 15 rows and 10 columns with a 1.4mm pitch. The connector uses press-fit termination for reliable board attachment and is designed for right-angle board edge mounting. Gold-plated contacts provide durability and signal integrity. The housing is made of high-temperature thermoplastic with UL94V-0 flame rating. Electrical performance includes a current rating of 0.5A per contact and differential impedance options of 100Ω or 85Ω, supporting data rates up to 12.5Gb/s. This connector is suitable for backplane, midplane, and coplanar applications in telecom, networking, server, and storage systems.

10034475-101LF Quick Information

Product Type: Backplane Receptacle
Series: AIRMAX VS
Canonical Name: Amphenol ICC 10034475-101LF - High Speed Backplane Receptacle, 150 Positions, Press-Fit
Subcategory: High Speed Backplane Connector

10034475-101LF Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

10034475-101LF Estimated Pricing

Qty Low High
4+ $22.47 $22.47

Estimated market price range - modelled values for guidance only, not live distributor offers.

10034475-101LF Features

  • 150 positions in 15 rows with 1.4mm pitch.
  • Press-fit termination for reliable board attachment.
  • Gold-plated contacts with 30µin thickness.
  • Rated for 0.5A per contact.
  • Suitable for data rates up to 12.5Gb/s.

10034475-101LF Applications

  • Used in telecom backplane systems.
  • Ideal for networking switches and routers.
  • Suitable for server and storage applications.
  • Supports high-speed data transmission in data centers.

10034475-101LF FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the 10034475-101LF have?

150 positions.

What is the pitch of this connector?

1.4mm (0.055 inches).

What is the current rating per contact?

0.5A per contact.

What is the mounting type?

Board edge, through hole, right angle mounting with press-fit termination.

What is the contact finish?

Gold, 30µin (0.76µm) thickness.

How many rows does this connector have?

15 rows.

What is the differential impedance?

Either 100Ω ±8Ω or 85Ω ±5Ω, depending on the design variant. The specific impedance for this part number is not confirmed.
