| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
27 pcs
|
27 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Arrangement | |
| Number of Contacts | |
| Termination Method |
This ITW Pancon connector, part number 100-064-433, belongs to the HI-CON Type B Series 100 family. It is a female connector designed for printed circuit board applications, featuring a two-row layout and a total of 64 contacts. The termination method employed is press-fit, which offers a reliable connection without soldering.
The connector is specified for PCB thicknesses ranging from 1.6 to 3.2 mm, with a finished hole size requirement of 0.94 to 1.09 mm and a drill size of 1.15 ± 0.01 mm. Copper thickness on the PCB should be between 25-76 µm, with a tin-lead plating thickness of at least 6 µm.
This component is suitable for various electronic assemblies requiring robust and high-density interconnects. Its press-fit design simplifies assembly processes and ensures mechanical stability.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The ITW Pancon 100-064-433 connector has 64 contacts.
The contacts are arranged in two rows.
It uses a press-fit termination method.
The recommended PCB thickness is between 1.6 and 3.2 mm.
The finished hole size should be between 0.94 and 1.09 mm.
The drill size is 1.15 ± 0.01 mm.
The copper thickness should be between 25 and 76 µm.
