| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
8,185 pcs
|
8185 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Termination Style |
The TE Connectivity 1-826632-0 is a 20-position, dual-row, unshrouded header designed for board-to-board or cable connections. It features a 2.54mm pitch and row spacing, making it compatible with standard prototyping and production PCBs. The header uses male square pins made of brass with a tin finish, providing reliable solderability and corrosion resistance. The overall contact length is 12.70mm, with a mating contact length of 6.70mm and an insulation height of 2.79mm. The green PBT insulator is rated UL94 V-0 for flammability. This through-hole component is terminated by soldering and has a push-pull fastening type. It is rated for 5A current and operates over a temperature range of -65°C to 105°C. The part is listed as RoHS3 compliant, though this status is unverified.
20 positions in 2 rows.
2.54mm (0.100").
5A.
Through hole with solder termination.
Tin, 3.90µin (0.099µm) thickness.
-65°C to 105°C.
No, it is unshrouded.
