1-826469-4 This TE Connectivity header connector features 28 positions in a 2.54mm pitch, through hole mounting, and tin-plated phosphor bronze contacts. It is shrouded with a latch holder for secure mating.
Mfr Part #:

1-826469-4

Available from 1 distributors
Mfr Name: TE Connectivity
TE Connectivity
This TE Connectivity header connector features 28 positions in a 2.54mm pitch, through hole mounting, and tin-plated phosphor bronze contacts. It is shrouded with a latch holder for secure mating.
✓ Total Stock: 2,000 pcs
$ Price Range: $10.14

1-826469-4 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Husky International Electronic ✓
Non-Authorised Inventory information
2,000 pcs
On Request
2000 pcs On Request 1 On Request On Request N/A On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

1-826469-4 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Fastening Type
Insulation Color
Insulation Height
Insulation Material
Lead Spacing
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Pitch
Row Spacing
Shrouding
Style
Tape & Reel
Termination
View Similar Products (0)

1-826469-4 Description

Short technical summary and product information.

The TE Connectivity 1-826469-4 is a 28-position male pin header connector designed for board-to-board or cable applications. It features a 2.54mm pitch and 2 rows of contacts, with a shrouded 2-wall design and latch holder fastening for reliable connections. The header is through-hole mounted and terminated via solder, making it suitable for standard PCB assembly processes. The insulation is black glass-filled PCT with a UL94 V-0 flammability rating, and the contacts are phosphor bronze with a tin finish (3.90µin thickness). Operating temperature range is -55°C to 105°C. This connector is RoHS3 compliant and has an MSL of 1 (unlimited).

1-826469-4 Quick Information

Product Type: Header, Male Pins
Canonical Name: TE Connectivity 1-826469-4 Header, Male Pins, 28 Position, 2.54mm Pitch, Through Hole
Subcategory: Male Pins

1-826469-4 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

1-826469-4 Estimated Pricing

Qty Low High
500+ $10.14 $10.14

Estimated market price range - modelled values for guidance only, not live distributor offers.

1-826469-4 Features

  • 28 positions in 2 rows with 2.54mm pitch.
  • Through-hole mounting with solder termination.
  • Shrouded 2-wall design with latch holder.
  • Tin-plated phosphor bronze contacts.
  • UL94 V-0 rated black PCT insulation.

1-826469-4 Applications

  • Board-to-board or cable interconnects.
  • General purpose signal connections.
  • Through-hole PCB assembly applications.

1-826469-4 FAQs

5 frequently asked questions generated from this part’s specifications.
How many positions does the 1-826469-4 header have?

28 positions.

What is the pitch of this TE Connectivity header?

2.54mm (0.100").

What is the mounting type for this connector?

Through hole.

What is the operating temperature range?

-55°C to 105°C.

What contact finish does this header have?

Tin with 3.90µin thickness.
