| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,200 pcs
|
1200 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Length - Mating | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Height | |
| Overall Length (L) | |
| Pitch | |
| Shrouding | |
| Style | |
| Termination | |
| Termination Style |
The TE Connectivity AMPMODU II 1-825437-0 is a 10-position, single-row, unshrouded breakaway header designed for board-to-board or cable applications. It features a 2.54mm pitch and a right-angle through hole mounting style with solder termination.
This header uses square male pins made of brass with a tin finish on the solder side and a palladium-nickel plus gold flash on the mating side. The green PBT insulator is rated UL94 V-0 for flammability. The connector is rated for 5A and operates from -65°C to 105°C.
The overall length is 25.40mm with an insulation height of 2.54mm and a mating pin length of 6.70mm. The push-pull fastening type and unshrouded design make it suitable for breakaway applications.
The pitch is 2.54mm.
It has 10 positions in a single row.
The current rating is 5A.
Through hole, right angle mounting with solder termination.
-65°C to 105°C.
Green PBT (Polybutylene Terephthalate) rated UL94 V-0.
