| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,600 pcs
|
1600 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
114 pcs
|
114 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Voltage Rating |
The TE Connectivity 1-770874-0 is a 4-position, 2-row, shrouded header male pin connector designed for board-to-cable/wire applications. It features a 4.14mm pitch and row spacing, with circular brass contacts finished in 150µin tin. The header has a through hole termination with solder connection. The white polyamide (nylon) insulation carries a UL94 V-0 flammability rating and the operating temperature range is -20°C to 85°C. The connector includes a board lock feature and a locking ramp fastening type for secure mating. It is rated for 600VAC operation with current rating dependent on wire gauge.
This connector has 4 positions, all loaded, in 2 rows.
The pitch is 4.14mm (0.163") with the same row spacing.
The voltage rating is 600VAC.
It uses through hole mounting with solder termination.
The operating temperature range is -20°C to 85°C.
The part is listed as RoHS3 compliant, though this has not been independently verified.
