| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,500 pcs
|
1500 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Cable Termination | |
| Color | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Type | |
| Fastening Type | |
| Features | |
| Lead Spacing | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Pitch | |
| Wire Gauge | |
| Wire Type |
This is a 18 position rectangular connector receptacle from TE Connectivity. It features a single row of female socket contacts with a 2.54mm (0.100") pitch. The connector is designed for free hanging (in-line) right angle mounting and uses IDC (Insulation Displacement Contact) termination for 26 AWG discrete or ribbon cable. The contacts have a tin-lead finish with 80.0µin (2.03µm) thickness. The housing is blue and includes a locking ramp fastening type for secure mating. This is a closed end version, meaning the connector is terminated at one end. It is suitable for applications requiring a compact, reliable wire-to-board or wire-to-wire connection.
18 positions.
2.54mm (0.100").
Free hanging (in-line), right angle.
IDC (Insulation Displacement Contact).
26 AWG.
Tin-lead with 80.0µin (2.03µm) thickness.
Blue.
