1/2A24-N30-E
Advanced Energy
The Advanced Energy 1/2A24-N30-E is a 30W DC-DC converter with an output voltage range of 0-500VDC. It is designed for chassis mounting.
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Height | |
| Input Impedance | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Power | |
| Output Voltage | |
| Power (Watts) | |
| Ripple | |
| Stability | |
| Standard Number | |
| Tape & Reel | |
| Type | |
| Voltage | |
| Voltage Range | |
| Width |
The Advanced Energy A Series 1/2A24-P30-C is a miniature, PCB-mount, high voltage, regulated DC-DC converter. Designed with state-of-the-art power-conversion topology, it features surface-mount technology and encapsulation for high reliability.
This converter provides up to 30W of output power with an output voltage range of 0 to 500 VDC and a maximum output current of 60 mA. It operates with an input voltage range of 11 to 16 VDC (full power) or 9 to 32 VDC (derated power). Key electrical specifications include low ripple (0.017% V p-p) and high line and static load regulation (<0.01%).
The unit is designed for chassis mounting and operates within a temperature range of -40°C to 65°C. It is recognized as a UL/cUL component and carries the CE Mark for LVD and RoHS compliance. Typical applications include bias supplies, electrostatic detectors, mass spectrometers, and photomultiplier tubes.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The input voltage range is 11 to 16 VDC.
The maximum output voltage is 500 VDC.
The rated output power is 30 W.
The dimensions are 120.7 mm in length, 50.8 mm in width, and 25.4 mm in height.
The operating temperature range is -40°C to 65°C.
