| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
34 pcs
|
34 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | 2026-05-08 04:16:26 |
| Category | |
| Manufacturer Name | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Material | |
| Features | |
| Halogen Free | |
| Housing Material | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions or Pins (Grid) | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| SVHC Present | |
| Storage Temperature | |
| Termination | |
| Type |
The TE Connectivity 1-2199298-6 is a 20 position DIP IC socket designed for through hole mounting. It features a 2.54mm (0.100") pitch and 0.3" (7.62mm) row spacing, making it suitable for standard DIP package ICs. The socket uses phosphor bronze contacts with a tin finish (60.0µin thickness) for reliable electrical connections. The housing is made of glass-filled polybutylene terephthalate (PBT) thermoplastic, offering good mechanical strength and thermal stability.
This open frame socket allows for airflow and cleaning around the contacts. It has an operating temperature range of -40°C to 105°C, making it suitable for a variety of environments. The socket is RoHS3 compliant and REACH unaffected, with an MSL rating of 1 (unlimited).
Designed for use in prototyping, production, and testing applications, this socket provides a reliable interconnect between ICs and circuit boards. Its solder termination ensures secure attachment to the PCB.
20 positions.
2.54mm (0.100").
Through hole.
0.3" (7.62mm).
Tin with 60.0µin thickness.
-40°C to 105°C.
RoHS3 compliant (unverified, low confidence).
