| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,382 pcs
|
2382 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Cable Termination | |
| Color | |
| Connector Type | |
| Contact Finish | |
| Contact Material | |
| Contact Plating | |
| Contact Type | |
| Features | |
| Housing Material | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Packaging Type | |
| Pitch | |
| Row Spacing | |
| Standard Package Qty | |
| Wire Gauge | |
| Wire Type |
The TE Connectivity 1-215083-8 is a Micro-MaTch series male-on-wire IDC connector designed for terminating 28 AWG ribbon cable. It features 18 positions arranged in 2 rows with a 2.54mm pitch and 1.50mm row spacing.
The connector uses IDC termination for reliable cable connection without stripping. The contacts are male pins made of phosphor bronze with a tin over nickel plating. The housing and cover are red glass filled polyester, a common material for good electrical insulation and mechanical strength.
With a free hanging (in-line) mount style, this connector is suited for internal wiring applications where a secure, removable connection to a ribbon cable is needed. The feed through feature allows daisy-chaining along a cable. Packaging options include a box of 250 or a reel of 2500 connectors.
The connector has 18 positions.
The contact pitch is 2.54mm (0.100 inches).
It terminates 28 AWG ribbon cable using IDC termination.
It is a free hanging (in-line) mount connector.
The contacts are phosphor bronze with tin over nickel plating, and the housing is red glass filled polyester.
