| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,516 pcs
|
2516 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The TE Connectivity 1-1827873-5 is a 10-position, 2-row, 2mm pitch rectangular header with male pins. It features a right angle orientation and through-hole mounting with solder termination. The header is fully shrouded with a 4-wall design and includes a detent lock for secure mating.
Electrical ratings are 3A current and 125V voltage. Operating temperature range is -55°C to 105°C. Contacts are copper alloy with tin finish (0.38µm thickness). The insulation material is thermoplastic, polyester, glass filled with UL94 V-0 flammability rating.
Mechanical details include a board lock for PCB attachment, insulation height of 11.80mm, and contact length of 3.10mm. Designed for board-to-board or cable applications. The component is specified as RoHS3 compliant, REACH unaffected, and MSL 1 (unlimited).
10 positions in 2 rows.
2.00mm
3A
125V
Through hole, right angle
-55°C to 105°C
Tin with 0.38µm thickness
