1-1571983-1 The TE Connectivity 1-1571983-1 is a slide-actuated DIP switch with SPST circuitry. It features a surface mount design and gull wing termination.
Mfr Part #:

1-1571983-1

Available from 3 distributors
Mfr Name: TE Connectivity
TE Connectivity
The TE Connectivity 1-1571983-1 is a slide-actuated DIP switch with SPST circuitry. It features a surface mount design and gull wing termination.
✓ Total Stock: 4,422 pcs
$ Price Range: $0.75

1-1571983-1 Available from 3 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Xingangxin ✓
Non-Authorised Inventory information
2,900 pcs
On Request
2900 pcs On Request 1 On Request On Request On Request On Request On Request
Partservice ✓
Non-Authorised Inventory information
1,465 pcs
On Request
1465 pcs On Request 1 On Request On Request On Request On Request On Request
Speed Components Ltd ✓
Non-Authorised Inventory information
57 pcs
On Request
57 pcs On Request 1 On Request On Request 1239 On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

1-1571983-1 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Actuator Level
Actuator Type
Circuit
Contact Finish
Contact Material
Current Rating (Amps)
Features
Height Above Board
Mounting Type
Number of Positions
Operating Temperature
Pitch
Tape & Reel
Termination Style
Voltage Rating
Washable
View Similar Products (0)

1-1571983-1 Description

Short technical summary and product information.

This TE Connectivity 1-1571983-1 is a single-pole, single-throw (SPST) slide DIP switch designed for surface mounting. It offers 8 positions and operates with a voltage rating of 24VDC and a current rating of 25mA.



The switch features a gull wing termination style and a contact finish of gold over a copper alloy contact material. It has a pitch of 1.27mm (0.050 inches) and a height above board of 2.30mm (0.091 inches). The operating temperature range is from -30°C to 85°C.



Designed for applications requiring a washable switch, this component has a tape seal feature. The actuator level can be flush or recessed, with a standard slide actuator type. It is classified under RoHS3 compliance and has a Moisture Sensitivity Level (MSL) of 1.

1-1571983-1 Quick Information

Product Type: DIP Switch
Canonical Name: TE Connectivity 1-1571983-1 SPST Slide DIP Switch
Subcategory: Slide DIP Switch

1-1571983-1 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

1-1571983-1 Estimated Pricing

Qty Low High
1+ $0.75 $0.75

Estimated market price range - modelled values for guidance only, not live distributor offers.

1-1571983-1 Features

  • SPST slide DIP switch with 8 positions.
  • Rated for 24VDC and 25mA current.
  • Surface mount with gull wing termination.
  • Operates from -30°C to 85°C.
  • Washable with tape seal feature.

1-1571983-1 Applications

  • Ideal for board-level configuration.
  • Suitable for automated assembly processes.
  • Used in compact electronic designs.
  • Requires washable switch capability.

1-1571983-1 FAQs

5 frequently asked questions generated from this part’s specifications.
What is the voltage rating for the 1-1571983-1 DIP switch?

The voltage rating is 24VDC.

What is the operating temperature range for this DIP switch?

The operating temperature range is -30°C to 85°C.

What type of mounting is required for the 1-1571983-1?

This DIP switch requires surface mounting.

What is the RoHS status of the 1-1571983-1?

The RoHS status is RoHS3 Compliant.

What is the Moisture Sensitivity Level (MSL) for this component?

The Moisture Sensitivity Level is 1 Unlimited.
