1-146134-6 TE Connectivity 1-146134-6 is a 6 position, 2 row, 2.54mm pitch surface mount header with male pin contacts, tin finish, rated 3A per contact and 30VAC.
Mfr Part #:

1-146134-6

Available from 1 distributors
Mfr Name: TE Connectivity
TE Connectivity
TE Connectivity 1-146134-6 is a 6 position, 2 row, 2.54mm pitch surface mount header with male pin contacts, tin finish, rated 3A per contact and 30VAC.
✓ Total Stock: 7,568 pcs

1-146134-6 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
7,568 pcs
On Request
7568 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

1-146134-6 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating (Amps)
Fastening Type
Insulation Color
Insulation Height
Insulation Material
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Pitch
Row Spacing
Shrouding
Style
Tape & Reel
Termination
Termination Style
Voltage Rating
View Similar Products (0)

1-146134-6 Description

Short technical summary and product information.

The TE Connectivity 1-146134-6 is a 6-position, 2-row unshrouded breakaway header designed for surface mount soldering. It features a 2.54mm pitch and row spacing, making it suitable for board-to-board or cable-to-board interconnects. The male pin contacts are made of copper alloy with a tin finish (2.54µm thickness) and have a mating contact length of 5.84mm. The insulator is black liquid crystal polymer (LCP) with a UL94 V-0 flammability rating. This connector is rated for 3A per contact and 30VAC, with an operating temperature range of -65°C to 125°C. The push-pull fastening type allows easy mating and unmating.

1-146134-6 Quick Information

Product Type: Header, Male Pins
Canonical Name: TE Connectivity 1-146134-6 6 Position 2.54mm Pitch Surface Mount Header
Subcategory: Breakaway Header

1-146134-6 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

1-146134-6 Features

  • 6 position 2 row unshrouded header.
  • 2.54mm pitch and row spacing.
  • Surface mount solder termination.
  • Tin plated copper alloy contacts.
  • Rated 3A per contact at 30VAC.

1-146134-6 Applications

  • Board-to-board interconnect applications.
  • Cable-to-board connector systems.
  • General purpose signal connections.

1-146134-6 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the pitch of this header?

The pitch is 2.54mm (0.100") and the row spacing is also 2.54mm.

How many positions does this connector have?

It has 6 positions arranged in 2 rows, all positions loaded.

What is the current rating per contact?

The current rating is 3A per contact.

What is the voltage rating?

The voltage rating is 30VAC.

What mounting type does this header use?

It is surface mount (SMD) with solder termination.

What is the operating temperature range?

The operating temperature range is -65°C to 125°C.

What is the contact material and finish?

The contacts are copper alloy with a tin finish (2.54µm thickness).
