1-1102291-1 TE Connectivity 1-1102291-1 heavy duty connector base, panel mount, bottom entry, Size 8. Rated IP65 with gray powder coated aluminum housing.
Mfr Part #:

1-1102291-1

Available from 1 distributors
Mfr Name: TE Connectivity
TE Connectivity
TE Connectivity 1-1102291-1 heavy duty connector base, panel mount, bottom entry, Size 8. Rated IP65 with gray powder coated aluminum housing.
✓ Total Stock: 5 pcs
$ Price Range: $30.28 - $37.05

1-1102291-1 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Fe Components ✓
Non-Authorised Inventory information
5 pcs
On Request
5 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

1-1102291-1 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Height
Housing Color
Housing Finish
Housing Material
Ingress Protection
Length
Lock Location
Style
Tape & Reel
Width
View Similar Products (0)

1-1102291-1 Description

Short technical summary and product information.

This TE Connectivity heavy duty connector base (part number 1-1102291-1) is a panel mount base with bottom entry style, designed for Size 8 connector systems. The housing is constructed from die cast aluminum alloy with a gray powder coated finish, providing durability and corrosion resistance.



The base includes two locking clips on the bottom for secure mating. It is rated IP65 for dust tight and water resistant protection, making it suitable for industrial environments where moisture and particulate ingress are concerns.



Mechanical dimensions: 140.00mm length x 43.50mm width x 28.50mm height. The housing color is gray, and the base is intended for panel mount applications requiring a bottom entry cable orientation.

1-1102291-1 Quick Information

Product Type: Heavy Duty Connector Base
Series: HB.24.AG-VS
Canonical Name: TE Connectivity 1-1102291-1 Heavy Duty Connector Base, Panel Mount, Bottom Entry, Size 8
Subcategory: Base - Panel Mount

1-1102291-1 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: Non-Compliant

1-1102291-1 Estimated Pricing

Qty Low High
1+ $37.05 $37.05
10+ $31.49 $31.49
25+ $30.28 $30.28

Estimated market price range - modelled values for guidance only, not live distributor offers.

1-1102291-1 Features

  • Panel mount base with bottom entry.
  • Gray powder coated aluminum alloy housing.
  • Rated IP65 for dust and water resistance.
  • Two locking clips on base bottom.
  • Size 8 heavy duty connector series.

1-1102291-1 Applications

  • Heavy duty industrial connector systems.
  • Panel mount applications needing bottom entry.
  • Environments requiring IP65 protection.
  • Size 8 compatible connector assemblies.

1-1102291-1 FAQs

6 frequently asked questions generated from this part’s specifications.
What is the connector type of this part?

Base - Panel Mount

What is the ingress protection rating?

IP65 - Dust Tight, Water Resistant

What is the housing material and finish?

Aluminum Alloy, Die Cast with Powder Coated finish, color Gray

What are the dimensions of this base?

Length: 140.00mm, Width: 43.50mm, Height: 28.50mm

What style of entry does this base use?

Bottom Entry

What locking mechanism is provided?

Locking Clip (2) on Base Bottom
