| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
20 pcs
|
20 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The TE Connectivity 1-104069-4 is a 34-position, 2-row shrouded header with male pin contacts. It features a 1.27mm pitch and 2.54mm row spacing, making it suitable for high-density board-to-board or cable connections. The connector is through hole mounted with a right angle orientation, and uses solder termination. It includes a latch holder for secure mating and a board guide for alignment. The contacts are made of copper alloy with a tin-lead finish, and the black thermoplastic insulator is rated UL94 V-0 for flammability. The operating temperature range is -65°C to 105°C, and the voltage rating is 30VAC.
The pitch is 1.27mm.
It has 34 positions in 2 rows.
Through hole, right angle.
30VAC.
-65°C to 105°C.
