09664517513 Harting 09664517513 is a 37-position D-Sub receptacle connector with female sockets. It features through hole solder termination, board locks, and a current rating of 6.5A.
Mfr Part #:

09664517513

Available from 1 distributors
Mfr Name: Harting
Harting
Harting 09664517513 is a 37-position D-Sub receptacle connector with female sockets. It features through hole solder termination, board locks, and a current rating of 6.5A.
✓ Total Stock: 50 pcs

09664517513 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
50 pcs
On Request
50 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

09664517513 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Style
Connector Type
Contact Type
Current Rating
Current Rating (Amps)
Features
Flange Feature
Lead Spacing
Lead Style
Material Flammability Rating
Mounting Type
Number of Positions
Number of Rows
Package / Case
SVHC Present
Shell Material
Shell Material, Finish
Shell Size
Shell Size, Connector Layout
Storage Temperature
Termination
Termination Style
View Similar Products (0)

09664517513 Description

Short technical summary and product information.

The Harting 09664517513 is a D-Sub receptacle connector designed for reliable signal connectivity in industrial applications.



It offers 37 female socket contacts arranged in two rows, with a shell size of 4 (DC, C) and a steel shell for EMI shielding and mechanical strength. The connector is mounted via through hole technology and terminated by solder, providing a robust connection to the PCB. It includes board locks for secure PCB retention and female screwlocks (4-40) on the mating side for locking with the male connector.



Electrical rating is 6.5A per contact. The insulator material is UL94 V-0 rated for flammability. This connector is RoHS3 compliant and has an MSL of 1 (unlimited).

09664517513 Quick Information

Product Type: D-Sub Connector Assembly
Series: D-Sub
Canonical Name: Harting 09664517513 D-Sub Receptacle Connector, Female Sockets, 37 Positions, Through Hole, Solder, Board Lock, Female Screwlock (4-40)
Subcategory: Standard D-Sub

09664517513 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

09664517513 Features

  • 37-position D-Sub receptacle with female sockets.
  • Through hole solder termination for PCB mounting.
  • Board locks for secure retention on PCB.
  • Female screwlocks (4-40) on mating side.
  • Rated for 6.5A per contact.

09664517513 Applications

  • Used in industrial control and automation systems.
  • Suitable for data communication equipment.
  • Ideal for test and measurement instruments.
  • Common in computer peripheral connections.

09664517513 FAQs

5 frequently asked questions generated from this part’s specifications.
How many positions does the Harting 09664517513 have?

It has 37 positions (female sockets) arranged in 2 rows.

What is the current rating of this D-Sub connector?

The current rating is 6.5 A per contact.

What is the mounting type for the 09664517513?

It is a through hole mounting connector with solder termination.

Does this connector include board locks?

Yes, it features board locks for secure PCB retention.

What is the shell size and material?

Shell size is 4 (DC, C) and the shell material is steel.
