| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
70 pcs
|
70 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Backset Spacing | |
| Connector Style | |
| Connector Type | |
| Contact Type | |
| Current Rating (Amps) | |
| Features | |
| Flange Feature | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| SVHC Present | |
| Shell Material, Finish | |
| Shell Size, Connector Layout | |
| Storage Temperature | |
| Termination | |
| Termination Style |
This D-Sub connector from Harting is a plug with 25 male pins arranged in 2 rows. It features a right angle through hole mounting style with solder termination, making it suitable for PCB applications where space is limited. The connector has a DB B shell size with a steel shell and includes a housing/shell flange with 4-40 threads for secure mating.
The contacts are rated for signal applications with a current rating of 6.5A. The insulator material has a UL94 V-0 flammability rating, ensuring fire safety. The backset spacing is 0.409" (10.40mm), providing clearance for board mounting.
Additional features include board locks for secure attachment to the PCB and grounding indents for improved EMI performance. This connector is designed for reliable connections in data communication, industrial control, and computer peripheral interfaces.
| Qty | Low | High |
|---|---|---|
| 1+ | $8.78 | $8.78 |
| 10+ | $7.91 | $7.91 |
| 20+ | $7.61 | $7.61 |
| 100+ | $6.46 | $6.46 |
| 200+ | $6.29 | $6.29 |
| 500+ | $5.91 | $5.91 |
| 1,000+ | $5.22 | $5.22 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
25 positions.
6.5A.
Through hole, right angle.
DB B (3).
Board lock and grounding indents.
UL94 V-0.
Solder.
