| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
148 pcs
|
148 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Contact Resistance | |
| Insulation Resistance | |
| Mating Cycles | |
| Mounting Type | |
| Number of Contacts | |
| Prop 65 | |
| Rated Current | |
| SVHC Present | |
| Termination Style |
This Harting D-Sub HD FE STR 15P PL3 connector, part number 09561517500, is a high-density D-Sub connector assembly. It features 15 positions and a stamped straight contact version suitable for wave soldering termination.
The connector operates with a rated current of 2A and has an insulation resistance greater than 5 GΩ. The operating temperature range is from -40°C to +85°C, with a mating cycle rating of 50.
Constructed with a thermoplastic resin, glass-fibre filled (PBTP) insert and a steel, nickel-plated shell, this connector meets UL 94 V-0 flammability standards. The contact material is copper alloy with noble metal plating on the mating side and Sn over Ni on the termination side.
It is designed with a fixing flange and a feed-through hole of 3.1 mm for mounting. The connector is RoHS3 compliant and REACH unaffected.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.00 | $1.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The Harting 09561517500 has 15 contacts.
The rated current for the Harting 09561517500 is 2 A.
The test voltage of the Harting 09561517500 is 1 kV.
The insulation resistance of the Harting 09561517500 is greater than 5 GΩ.
The contact resistance of the Harting 09561517500 is 20 mΩ.
The operating temperature range for the Harting 09561517500 is -40 to +85 °C.
The material flammability class of the Harting 09561517500 is V-0 according to UL 94.
