The Phoenix Contact 0915031 is a fuse modular terminal block designed for electrical connections. It has a nominal current rating of 0.1A and a nominal voltage of 250V AC, with a DC rating of 65V.
This terminal block supports conductor cross-sections ranging from 0.2 mm² to 6 mm² for solid conductors and 0.2 mm² to 4 mm² for stranded conductors, accommodating AWG sizes from 24 to 10. The connection method is screw connection, with a stripping length of 12 mm and an M3 screw thread. The tightening torque should be between 0.6 Nm and 0.8 Nm.
Constructed from PA-F insulating material, it meets an inflammability class of V0 according to UL 94. The terminal block has 2 positions and 4 connections, with a width of 25 mm. It is designed for mounting on a 35 mm DIN rail.
Environmental specifications include a pollution degree of 3 and a surge voltage category of III. The operating temperature range is from -30 °C to 60 °C. The insulating material group is I.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The current rating is 100mA.
The maximum voltage is 250V AC.
It mounts on a DIN rail.
The insulating material is PA-F.
It has a V0 flammability class according to UL 94.
-30°C to 60°C.
