The Phoenix Contact 0914277 is a thermomagnetic circuit breaker designed for reliable circuit protection. This 1-pole device features a fast-blow characteristic and a 1 N/C contact.
With a nominal current rating of 2A, it is suitable for applications requiring protection against overcurrents and short circuits. The voltage rating is 250VAC and 65VDC, making it versatile for various power systems. The breaker is designed for DIN rail mounting, facilitating easy installation in control panels and enclosures.
Connection is made via screw terminals, supporting solid and stranded conductors ranging from 0.2 mm² to 6 mm². The device operates within an ambient temperature range of -30°C to 60°C and has an insulating material class of V-2 according to UL 94.
Key specifications include a width of 12.5 mm, and various height dimensions depending on the mounting rail (NS 35/7.5, NS 35/15, or NS 32). The pollution degree is rated at 2, and it falls under Surge Voltage Category II.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The nominal current rating is 2A.
It is rated for 250VAC and 65VDC.
It is designed for DIN rail mounting.
It is a thermomagnetic circuit breaker.
The operating temperature range is -30°C to 60°C.
It supports solid conductors from 0.2 mm² to 6 mm² and stranded conductors from 0.2 mm² to 4 mm².
