| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Color | |
| Connection Method | |
| Current Rating | |
| Current Rating (Amps) | |
| Depth | |
| Fuse Type | |
| Height | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Tape & Reel | |
| Voltage Rating | |
| Width |
The Phoenix Contact 0900139 is an electronic device circuit breaker with a single pole configuration. It is designed for operation at 24V DC, with a nominal current rating of 1A. This circuit breaker incorporates active current limitation for enhanced protection.
The device features a screw connection for easy installation and a compact width of 12.5 mm, making it suitable for space-constrained applications. It is mounted on a base element and has an automatic reset function. The circuit breaker operates within an ambient temperature range of 0°C to 50°C.
Compliance with standards such as UL 2367, UL 508, and CSA 22.2 No. is indicated. The insulating material is PA66/6 with a UL 94 V0 flammability rating. The circuit breaker has an overvoltage category of II and a degree of pollution of 2.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating voltage for the Phoenix Contact 0900139 circuit breaker is 24 V DC, with a range of 18 V DC to 32 V DC.
The nominal current rating for the Phoenix Contact 0900139 circuit breaker is 1 A.
The 0900139 circuit breaker uses an electronic fuse type and is an automatic device, with no external backup fuse required as it has an integrated failsafe element.
The ambient operating temperature range for the Phoenix Contact 0900139 is 0 °C to 50 °C.
This circuit breaker is designed for mounting on a base element.
