| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
445 pcs
|
445 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Features | |
| Halogen Free | |
| Industrial Grade | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| SVHC Present | |
| Shrouding | |
| Style | |
| Termination |
The Molex 0878320606 is a 6-position, 2-row, 2.00mm pitch surface mount shrouded header designed for board-to-board or cable applications. It features a 4-wall shrouded housing with a latch holder for secure mating, and includes board guide and pick-and-place features for automated assembly.
The header uses tin-plated phosphor bronze square pins with a contact length of 3.60mm and an insulation height of 6.40mm. The housing is molded from glass-filled polyamide (nylon) with a UL94 V-0 flammability rating, and is colored black. The operating temperature range is -55°C to 105°C.
This connector is terminated via solder to a surface mount PCB. All 6 positions are loaded. The part is RoHS3 compliant and has an MSL of 1 (unlimited).
The pitch is 2.00mm (0.079 inches).
It has 6 positions arranged in 2 rows.
It is a surface mount (SMD) component with solder termination.
The operating temperature range is -55°C to 105°C.
The contacts are made of phosphor bronze with a tin finish of 0.38µm (15.0µin).
The part is listed as RoHS3 Compliant, but this is unverified.
