0878313020 Molex 0878313020 is a 30-position, 2-row, 2.00mm pitch through-hole header with shrouded 4-wall design and latch holder. It features tin-plated phosphor bronze contacts and a black polyamide insulator rated UL94 V-0.
Mfr Part #:

0878313020

Available from 1 distributors
Mfr Name: Molex
Molex
Molex 0878313020 is a 30-position, 2-row, 2.00mm pitch through-hole header with shrouded 4-wall design and latch holder. It features tin-plated phosphor bronze contacts and a black polyamide insulator rated UL94 V-0.
✓ Total Stock: 2 pcs

0878313020 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Emiteli ✓
Non-Authorised Inventory information
2 pcs
On Request
2 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

0878313020 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating
Current Rating (Amps)
Fastening Type
Features
Insulation Color
Insulation Height
Insulation Material
Lead Spacing
Lead Style
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Pitch
Row Spacing
Shrouding
Style
Termination
Voltage Rating
View Similar Products (0)

0878313020 Description

Short technical summary and product information.

The Molex 0878313020 is a 30-position, 2-row header connector with a 2.00mm pitch. It features a shrouded 4-wall design with latch holder for secure mating and a keying slot for polarization. The through-hole mounting with solder termination ensures reliable board attachment.



Electrical specifications include a current rating of 2A per contact and a voltage rating of 125V. The operating temperature range is -55°C to 105°C. The contacts are made of phosphor bronze with a tin finish of 0.38µm. The insulator is black polyamide (nylon) with glass filling, rated UL94 V-0.



This connector is suitable for board-to-board or cable-to-board applications. The shrouded design provides protection to the contact pins and prevents misalignment. The latch holder offers additional retention force. The product is listed as RoHS3 compliant, MSL 1, and REACH unaffected, though these compliance claims are unverified.

0878313020 Quick Information

Product Type: Header, Male Pins
Series: Milli-Grid
Canonical Name: Molex 0878313020 - 30 Position 2.00mm Pitch Through Hole Shrouded Header, Tin Plated
Subcategory: Shrouded Header

0878313020 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): Non-JEDEC
REACH Status: REACH Unaffected
Lead Free: Yes

0878313020 Features

  • Shrouded 4-wall design with latch holder.
  • 30 positions in 2 rows at 2.00mm pitch.
  • Rated 2A per contact and 125V.
  • Through-hole mounting with solder termination.
  • Operating temperature -55°C to 105°C.

0878313020 Applications

  • Board-to-board and cable-to-board connections.
  • Industrial control and automation systems.
  • Consumer electronics and data communication.
  • General purpose wire-to-board applications.

0878313020 FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the Molex 0878313020 have?

The connector has 30 positions (all loaded in a 2-row configuration).

What is the pitch of this header?

The pitch is 2.00mm.

What is the current rating per contact?

The current rating is 2A per contact.

What is the voltage rating of the connector?

The voltage rating is 125V.

What is the mounting type for this header?

It is a through-hole mount with solder termination.

What is the operating temperature range?

The operating temperature range is -55°C to 105°C.

Is the header shrouded?

Yes, it has a shrouded 4-wall design with a latch holder and keying slot.
