The Molex 0877581016 is a 10-position, 2-row unshrouded breakaway header designed for board-to-board or cable applications. It features a 2.00mm pitch and 2.00mm row spacing, making it suitable for compact interconnect designs.
The header uses square tin-plated phosphor bronze contacts for reliable electrical performance. The insulator is black glass-filled polyamide (PA46/Nylon 4/6) with a UL94 V-0 flammability rating. Through-hole solder termination ensures a robust mechanical connection.
With an insulation height of 1.50mm and a contact length of 4.00mm (overall 8.10mm), this header provides adequate mating depth for standard connectors. The push-pull fastening type allows easy insertion and removal.
It has 10 positions arranged in 2 rows.
The pitch is 2.00mm (0.079 inches).
It is a through hole mount connector with solder termination.
The contacts are made of phosphor bronze with a tin finish (15.0µin thickness).
It is listed as RoHS3 compliant, but this is unverified.
