| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5,608 pcs
|
5608 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Overall Contact Length | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Termination Style |
The Molex 0877580616 is a 6-position, 2-row breakaway header with a 2.00mm pitch, designed for board-to-board or cable applications. This unshrouded through-hole header features tin-plated phosphor bronze square contacts with an overall contact length of 8.10mm and a contact length of 4.00mm.
The insulation is made of black polyamide (PA46) with glass fill, rated UL94 V-0 for flammability. The push-pull fastening type and 2.00mm row spacing make it suitable for compact PCB layouts. All 6 positions are loaded, and the insulation height is 1.50mm.
Typical applications include wire-to-board and board-to-board interconnects in industrial, consumer, and telecommunications equipment. The through-hole mounting provides reliable solder connections.
6 positions in 2 rows.
2.00mm pitch.
Through hole mounting with solder termination.
Polyamide (PA46), Nylon 4/6, Glass Filled with UL94 V-0 flammability rating.
Tin with 15.0µin thickness.
