| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
126 pcs
|
126 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Features | |
| Halogen Free | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Positions | |
| SVHC Present | |
| Storage Temperature | |
| Termination |
The Molex 0756405001 is an SFP (Small Form-factor Pluggable) receptacle with integrated cage in a ganged 2x1 configuration. It provides 40 positions arranged as 20 per port, supporting two SFP modules side by side. The connector uses through hole right angle mounting with press-fit termination for secure board attachment without soldering.
Key mechanical features include a board guide for alignment, EMI shielding for signal integrity, and an integrated light pipe for visual status indication. The contacts are finished with 30.0µin (0.76µm) gold for reliable electrical performance over repeated mating cycles.
This connector is designed for use in networking and telecommunications equipment where high-speed pluggable interfaces are required. The press-fit termination simplifies assembly and reduces processing steps compared to traditional soldered connectors.
It is an SFP (Small Form-factor Pluggable) receptacle with an integrated cage in a ganged 2x1 configuration.
It has 40 positions, arranged as 20 per port (2 ports).
Through hole, right angle with press-fit termination.
Gold with a thickness of 30.0µin (0.76µm).
Yes, it is EMI shielded and also includes a board guide and light pipe.
