| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
26 pcs
|
26 pcs | On Request | 1 | On Request | On Request | N/A | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Mounting Type | |
| Number of Columns | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Pitch | |
| Termination |
The Molex 0739446016 is a specialized backplane connector designed for high-density interconnection applications. It is a header with male pins configured in the HDM Guide B style, offering 72 positions arranged in 6 rows with 12 columns. The connector features a 2.00mm pitch, providing a compact yet reliable connection solution.
This connector uses through hole mounting with solder termination, ensuring a robust mechanical attachment to the PCB. The contacts are finished with 29.5µin (0.75µm) of gold, which provides excellent corrosion resistance and reliable electrical performance over many mating cycles. The housing is black in color, and all 72 positions are loaded.
Designed for use in backplane systems, this connector is suitable for applications requiring high pin counts in a dense form factor. The HDM Guide B style ensures proper alignment and mating with corresponding receptacles.
It has 72 positions, all loaded.
The pitch is 2.00mm (0.079 inches).
It is a through hole mount connector with solder termination.
The contact finish is gold with a thickness of 29.5µin (0.75µm).
It has 6 rows.
