| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,387 pcs
|
1387 pcs | On Request | 1 | On Request | On Request | N/A | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Shrouding | |
| Style | |
| Termination | |
| Voltage Rating |
The Molex 0705430275 is a 5-position, single-row, shrouded header connector designed for board-to-cable/wire applications. It features a 2.54mm pitch and through-hole mounting with solder termination.
The header has square male pins with a mating pin length of 6.10mm and overall contact length of 12.70mm. Contacts are made of phosphor bronze with a tin finish of 15.0µin (0.38µm). The insulation is black polyester, glass filled, with a height of 11.80mm. It includes a latch holder fastening type and is fully shrouded with 4 walls.
Rated for 250V, the connector operates over -40°C to 105°C. The insulation material has a UL94 V-0 flammability rating. It is RoHS3 compliant and has MSL 1 (unlimited).
Suitable for wire-to-board connections requiring secure latching. The through-hole design provides robust mechanical attachment to PCBs.
| Qty | Low | High |
|---|---|---|
| 3,360+ | $1.00 | $1.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
5 positions.
2.54mm.
250V.
Through hole.
-40°C to 105°C.
Tin, 15.0µin (0.38µm).
Yes, RoHS3 compliant.
