0702475051 Molex 0702475051 is a 50 position right angle shrouded header with 2.54mm pitch, through hole solder termination, and tin plated phosphor bronze contacts.
Mfr Part #:

0702475051

Available from 1 distributors
Mfr Name: Molex
Molex
Molex 0702475051 is a 50 position right angle shrouded header with 2.54mm pitch, through hole solder termination, and tin plated phosphor bronze contacts.
✓ Total Stock: 799 pcs
$ Price Range: $4.89 - $5.17

0702475051 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Husky International Electronic ✓
Non-Authorised Inventory information
799 pcs
On Request
799 pcs On Request 1 On Request On Request N/A On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

0702475051 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Fastening Type
Features
Insulation Color
Insulation Height
Insulation Material
Lead Spacing
Lead Style
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Pitch
Row Spacing
Shrouding
Style
Termination
View Similar Products (0)

0702475051 Description

Short technical summary and product information.

The Molex 0702475051 is a 50 position right angle shrouded header designed for board-to-board or cable applications. It features a 2.54mm pitch and 2 rows of male pin contacts with a square contact shape. The connector uses through hole mounting with solder termination and a right angle orientation.



The header is fully shrouded with a 4-wall design and includes a keying slot for proper alignment. The insulator is molded from black glass-filled PBT with a UL94 V-0 flammability rating. Contacts are made of phosphor bronze with a tin finish of 15.0 microinches. The insulation height is 8.89mm and the contact length is 6.10mm. Row spacing is also 2.54mm.



This connector is suitable for a variety of interconnection needs where a reliable, polarized, and robust header is required. The push-pull fastening type allows for easy mating and unmating.

0702475051 Quick Information

Product Type: Header, Male Pins
Series: C-Grid
Canonical Name: Molex 0702475051 50 Position Right Angle Shrouded Header, 2.54mm Pitch, Through Hole, Tin
Subcategory: Shrouded Header, Right Angle

0702475051 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 (Unlimited)
REACH Status: REACH Unaffected

0702475051 Estimated Pricing

Qty Low High
15+ $4.89 $4.89
2,560+ $5.17 $5.17

Estimated market price range - modelled values for guidance only, not live distributor offers.

0702475051 Features

  • 50 position right angle shrouded header.
  • 2.54mm pitch with 2 rows.
  • Through hole solder termination.
  • Tin plated phosphor bronze contacts.
  • UL94 V-0 glass-filled PBT insulator.

0702475051 Applications

  • Board-to-board interconnection applications.
  • Cable-to-board connection systems.
  • Industrial control and automation equipment.
  • Consumer electronics and peripheral devices.

0702475051 FAQs

5 frequently asked questions generated from this part’s specifications.
How many positions does the Molex 0702475051 header have?

50 positions, all loaded, in 2 rows.

What is the pitch of this Molex header?

2.54mm (0.100") pitch with 2.54mm row spacing.

What is the mounting type for the 0702475051?

Through hole, right angle with solder termination.

What is the contact material and finish?

Phosphor bronze contacts with a tin finish of 15.0 microinches.

Is the header shrouded?

Yes, it is a 4-wall shrouded header with a keying slot.
