| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
20,000 pcs
|
20000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | 2026-02-16 21:33:16 |
| Category | |
| Manufacturer Name | |
| Current Rating | |
| Fuse Type | |
| Height | |
| Length | |
| Material | |
| Mounting Type | |
| Plating | |
| Response Time | |
| Torque | |
| Voltage Rating |
The Bel Fuse 0672-0101-22 is a fuse clip designed for 6.3mm (1/4 inch) diameter cartridge fuses. It is manufactured from brass (65 Cu/35Zn) with a thickness of 0.020 inches and a full hard temper. The clip features bright tin plating, with a minimum thickness of 200 microinches over a nickel barrier plate.
This fuse clip is rated for up to 15A, though suitability at higher currents depends on fuse type, circuit conditions, and PCB design. It meets solderability standards per Mil-Std-202F, Method 208. The clip requires a minimum torque of 1.0 in-oz to twist a fuse and a minimum extraction force of 2 lbs to remove a fuse from a single clip.
The 0672-0101-22 is a PCB type fuse clip with an ear, supplied in bulk packaging. It is RoHS compliant. The "bel" logo is die stamped on one side for identification.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The fuse clip is rated for 15A.
The voltage rating is 250VAC.
The interrupting rating is 200A AC.
The response time is fast blow.
It accommodates 6.3mm diameter cartridge fuses.
The clip is made of brass with bright tin plating over a nickel barrier plate.
