0554562059 Molex 0554562059 is a 20-position, 1.25mm pitch surface mount right angle header with male pins. It features a shrouded 4-wall design, push-pull fastening, and tin-plated brass contacts.
Mfr Part #:

0554562059

Available from 1 distributors
Mfr Name: Molex
Molex
Molex 0554562059 is a 20-position, 1.25mm pitch surface mount right angle header with male pins. It features a shrouded 4-wall design, push-pull fastening, and tin-plated brass contacts.
✓ Total Stock: 248 pcs
$ Price Range: $0.66 - $1.13

0554562059 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Husky International Electronic ✓
Non-Authorised Inventory information
248 pcs
On Request
248 pcs On Request 1 On Request On Request N/A On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

0554562059 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Length
Contact Material
Contact Shape
Contact Type
Fastening Type
Features
Insulation Color
Insulation Height
Insulation Material
Lead Spacing
Lead Style
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Pitch
Shrouding
Style
Tape & Reel
Termination
Termination Style
View Similar Products (0)

0554562059 Description

Short technical summary and product information.

The Molex 0554562059 is a 20-position rectangular connector header designed for board-to-cable/wire applications. It features a 1.25mm pitch and a surface mount, right angle mounting style, making it suitable for compact designs where space is limited. The connector is fully shrouded with a 4-wall design, providing robust protection for the male pins. The push-pull fastening type ensures secure mating and easy disconnection. The header is constructed with a polyamide (nylon) insulator rated UL94 V-0 for flammability, and the contacts are made of brass with a tin finish. Additional features include a board guide and solder retention for reliable assembly. The natural insulation color aids in visual inspection. This connector is RoHS3 compliant and has an MSL of 1 (unlimited). It is commonly used in consumer electronics, industrial controls, and other applications requiring a reliable board-to-wire connection.

0554562059 Quick Information

Series: Mini Mi II 55456
Subcategory: Board to Cable/Wire Connector

0554562059 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

0554562059 Estimated Pricing

Qty Low High
100+ $0.72 $0.72
500+ $0.71 $0.71
1,000+ $0.69 $0.69
1,300+ $0.66 $0.66
3,750+ $1.13 $1.13

Estimated market price range - modelled values for guidance only, not live distributor offers.

0554562059 Features

  • 20 positions in a single row.
  • 1.25mm pitch for compact designs.
  • Surface mount, right angle orientation.
  • Shrouded 4-wall design protects pins.
  • UL94 V-0 rated nylon insulator.

0554562059 Applications

  • Ideal for board-to-cable/wire connections.
  • Used in consumer electronics and appliances.
  • Suitable for industrial control systems.
  • Compact design for space-constrained PCBs.

0554562059 FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the Molex 0554562059 header have?

20 positions.

What is the pitch of this connector?

1.25mm (0.049 inches).

What is the mounting type?

Surface mount, right angle.

What is the fastening type?

Push-pull.

What is the contact finish?

Tin.

What is the insulation material and flammability rating?

Polyamide (nylon) with UL94 V-0 rating.

Is this connector RoHS compliant?

RoHS3 compliant (unverified).
