| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,753 pcs
|
1753 pcs | On Request | 1 | On Request | On Request | N/A | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Material | |
| Cable End Type | |
| Connector | |
| Contact Finish | |
| Contact Material | |
| FFC, FCB Thickness | |
| Features | |
| Flat Flex Type | |
| Height Above Board | |
| Housing Material | |
| Lead Spacing | |
| Locking Feature | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The Molex 0545500994 is a 9-position FFC/FPC connector with a 0.50mm pitch, designed for surface mount right-angle mounting. It features top contacts and a slide lock for secure cable retention. The connector accepts FFC and FPC cables with a thickness of 0.30mm and supports straight or tapered cable ends.
Key specifications include a voltage rating of 50V, an operating temperature range of -20°C to 85°C, and a material flammability rating of UL94 V-0. The contacts are made of phosphor bronze with a tin bismuth finish, while the housing is liquid crystal polymer (LCP) and the actuator is polyphenylene sulfide (PPS). The connector includes solder retention and zero insertion force (ZIF) features.
This connector is suitable for applications requiring a compact, reliable interconnection for flat flexible cables, such as in consumer electronics, automotive, and industrial control systems. The surface mount design enables efficient automated assembly.
9 positions.
0.50mm (0.020").
50V.
Surface mount, right angle.
Slide lock.
-20°C to 85°C.
