The Molex 0536250474 is a 40-position, 2-row plug connector with outer shroud contacts. It features a 0.64mm pitch and surface mount design, making it suitable for compact board-to-board applications. The connector has gold-plated contacts with a thickness of 10µin (0.25µm) for reliable signal integrity. The height above board is 6.00mm, and it supports mated stacking heights of 7mm and 13mm, allowing flexibility in parallel PCB stacking. Included features such as board guide and solder retention aid in alignment and robust mechanical attachment during assembly. This connector is part of the Arrays, Edge Type, Mezzanine category and is RoHS3 compliant, with MSL 1 (Unlimited) for moisture sensitivity.
| Qty | Low | High |
|---|---|---|
| 1+ | $5.36 | $5.36 |
| 10+ | $4.55 | $4.55 |
| 25+ | $4.27 | $4.27 |
| 50+ | $4.06 | $4.06 |
| 100+ | $3.87 | $3.87 |
| 250+ | $3.63 | $3.63 |
| 500+ | $3.63 | $3.63 |
| 1,000+ | $3.77 | $3.77 |
| 2,000+ | $3.59 | $3.59 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
40 positions.
0.64mm (0.025 inches).
Surface mount.
Gold finish with 10µin (0.25µm) thickness.
7mm and 13mm.
Board guide and solder retention.
2 rows.
